2002 / 2002S Touchless Automatic Car Wash Machine – 360° No-Contact High Pressure Rollover Cleaning System
Fully automatic touchless rollover car wash with 360° rotating stainless steel spray arms. 5-8.5 min per car, 80-120L water, 60-100kg high pressure. CE certified, 3-year warranty. Available in 2002 (standard) and 2002S (customizable) configurations.
Products Description
Automatic
Commercial Grade
Model 2002 No-Contact Automatic Car Wash Machine
A high-performance touchless car wash system designed for gas stations, car wash centers, and fleet operators. Delivers scratch-free cleaning, intelligent drying, and smart remote management in one robust automatic car wash machine.
Product Overview
The Model 2002 no-contact car wash machine is a fully automatic car wash system built for operators who demand speed, safety, and low maintenance. Using high-pressure water jets and 360° rotating stainless-steel arms, it cleans vehicles without brushes or physical contact—protecting paint, wraps, and delicate trim.
Equipped with ultrasonic vehicle profiling, multi-liquid dosing, APP-based management, and vibrant LED status lighting, this automatic car wash machine turns any wash bay into a modern, unmanned, revenue-ready service station. (The Model 2002S shares the same platform and is available with customized specs; contact us for details.)
Why Choose the Model 2002?
True Touchless Cleaning
360° rotating 304 stainless-steel arms deliver high-pressure rinse (60–100 kg) and foam coverage without brushes, eliminating swirl marks and scratches.
Fast & Efficient Wash Cycle
A full wash takes only 5–8.5 minutes, with a 30-second high-pressure sweep around the vehicle to maximize throughput during peak hours.
Smart Detection & Safety
Ultrasonic + encoder positioning, 4D contour detection, electronic anti-collision, and leakage protection ensure safe, precise operation.
Powerful Drying System
Embedded moving dryers plus side blowers (4 kW × 6) remove water quickly, leaving a spot-free finish customers notice.
Built for Global Deployment
Multi-language OS, customizable voltage (default 380V/50Hz), APP remote control, and galvanized outdoor-grade steel for all climates.
Low Maintenance, Premium Parts
Mitsubishi PLC, Schneider electrics, German PA6 wheels, Eaton hoses, and 304 stainless nozzles deliver long-term reliability.
Frequently Asked Questions
Technical Specifications
| Model | 2002 (2002S customizable on request) |
|---|---|
| Power Supply | 380V / 50Hz three-phase (voltage customizable) |
| Rated / Peak Power | 25 kW / 35 kW |
| Installation Space (L×W×H) | 7500 × 3400 × 3100 mm |
| Max. Vehicle Size (L×W×H) | 5600 × 2600 × 2100 mm (customizable) |
| Track Length | 7000 mm |
| Machine Weight / Volume | 2000 kg / 12 m³ |
| Wash Time | 5–8.5 min / vehicle |
| High-Pressure Rinse | 60–100 kg pressure, 360° rotating stainless arms |
| Drying System | Embedded moving dryer + 6 × 4 kW side blowers |
| Water Consumption | 80–120 L / vehicle |
| Electricity Consumption | 0.8–1.0 kWh / vehicle |
| Chemical Dosing | Metering-pump automatic proportioning |
| Control System | Mitsubishi PLC + 10″ Delta HMI touchscreen |
| Safety | Ultrasonic detection, electronic anti-collision, leakage protection |
| Frame Material | 100×100×4 mm hot-dip galvanized steel + outdoor powder coating |
| Warranty | 3 years |
Ready to Upgrade Your Car Wash Bay?
Get a quote, layout drawing, or video demonstration for the Model 2002 no-contact automatic car wash machine. Our team supports English-language communication and global shipping.
